Bearing |
MS |
Bore |
Outside Diameter |
Widths |
|||||
d |
D |
B |
C |
||||||
+0.0000,-.0005 +0.000,-.013 |
+0.0000,-.0005 +0.000,-.013 |
+0.000,-.005 +0.00,-13 |
+0.000,-.005 +0.00.-.13 |
||||||
in. |
mm |
in. |
mm |
in. |
mm |
in. |
mm |
||
| KP3L (1) | -3A | 0.1900 |
4.826 |
0.6250 |
15.875 |
0.245 |
6.22 |
0.203 |
5.16 |
| KP3 | -3 | 0.1900 |
4.826 |
0.7774 |
19.746 |
0.297 |
7.54 |
0.270 |
6.86 |
| KP4 | -4 | 0.2500 |
6.350 |
0.9014 |
22.896 |
0.484 |
12.29 |
0.335 |
8.51 |
| KP5 | -5 | 0.3125 |
7.938 |
1.2500 |
31.750 |
0.558 |
14.17 |
0.375 |
9.52 |
| KP6 | -6 | 0.3750 |
9.525 |
1.4375 |
36.512 |
0.620 |
15.75 |
0.469 |
11.91 |
| KP8 | -8 | 0.5000 |
12.700 |
1.6875 |
42.862 |
0.620 |
15.75 |
0.500 |
12.70 |
| KP10 | -10 | 0.6250 |
15.875 |
1.9375 |
49.212 |
0.620 |
15.75 |
0.500 |
12.70 |
Bearing
Number |
d 1 |
r 1 |
r |
Wt. |
Radial Limit Load Rating |
Thrust Limit Load Rating |
||||||
| Approx. |
+.015,-.000 +0.38,-.00 |
+.015,-.000 +0.38,-.00 |
Approx. |
|||||||||
in. |
mm |
in |
mm |
in. |
mm |
lbs. |
kg |
lbs. |
N |
lbs. |
N |
|
| KP3L (1) | 0.280 |
7.11 |
0.005 |
0.13 |
0.010 |
0.025 |
0.01 |
0.005 |
1560 |
6950 |
700 |
3100 |
| KP3 | 0.331 |
8.41 |
0.005 |
0.13 |
0.022 |
0.056 |
0.03 |
0.014 |
1880 |
8300 |
900 |
4000 |
| KP4 | 0.387 |
9.83 |
0.005 |
0.13 |
0.032 |
0.081 |
0.04 |
0.018 |
2680 |
12000 |
1200 |
5300 |
| KP5 | 0.469 |
11.91 |
0.015 |
0.38 |
0.032 |
0.081 |
0.09 |
0.041 |
5620 |
25000 |
2500 |
11200 |
| KP6 | 0.591 |
15.01 |
0.015 |
0.38 |
0.032 |
0.081 |
0.15 |
0.068 |
7910 |
35500 |
3500 |
15600 |
| KP8 | 0.752 |
19.10 |
0.015 |
0.38 |
0.044 |
1.120 |
0.21 |
0.095 |
11810 |
52000 |
5200 |
23200 |
| KP10 | 0.850 |
21.59 |
0.015 |
0.38 |
0.044 |
1.120 |
0.28 |
0.127 |
14100 |
63000 |
6200 |
27500 |
{1) Bonded Teflon Seals.
Note: These bearings should not be used as track rollers, cam follower rolls, and the like.
